RTI 4CH HI/LO-Z DSP MATRIX AMP AMP-4-125

Product Code: RT-AMP4125

Brand
RTI
RRP: POA


Quantity In Cart:
Unit of Measure
EACH



3 Year
Technical Specifications
Brands RTI
Amp power 125W
Channel count 4
  • Details
  • Downloads
  • Where to Buy
  • Ordering

AMP-4-125 - 4 Channel 125W 8Ω, 2 Channel 70/100V 250W DSP Matrix Amplifier

The AMP-4-125 power amplifier delivers configurable and reliable high-performance audio power amplification for commercial and hospitality applications requiring a mix of low-impedance and high-impedance outputs. Featuring a compact 1U half-rack design, this DSP-enabled Class-D amplifier supports low-impedance 4Ω to 16Ω loudspeakers and high-impedance 70V/100V transformer-coupled loudspeakers. The AMP-4-125 accepts four analog inputs and one stereo S/PDIF digital input, delivering four low impedance mono channels (or two low impedance stereo zones) at 125W per channel, or two 70V/100V mono channels at 250W per channel.

For setup, the RTI web GUI offers effortless browser-based configuration of the installed system. DSP configuration options include multi-zone setup, input mixing, priority and ducking, restrictions, input and output EQ, S/PDIF output routing, high-pass filtering, speaker presets, delay, Wall-S1 controller configuration, sine wave generation, and more.

Included in the box:

  • AMP-4-125, power cord
  • 6-pin Phoenix input connectors (2)
  • 4-pin Phoenix output connectors (2)
  • 8-pin Phoenix GPIO socket connector (1)
  • adhesive rubber feet (4)

Features

  • Four analog audio source input channels (balanced or unbalanced) and one digital input (S/PDIF).
  • Two Lo-Z stereo or four Lo-Z mono output zones, two Hi-Z mono output zones, or a mix of them.
  • A Class D amplifier provides a robust and clear audio experience with 125 Watts @ 4Ω/8Ω per channel or 250 Watts @ 70V/100V per channel.
  • Daisy-chain multiple amplifiers to expand the number of zones by distributing up to two audio inputs or zones.
  • Built-in DSP allows fine-tuning of acoustic characteristics for each zone.
  • Easy configuration via LAN or Wi-Fi.
  • Offers IP and GPIO control options.
  • Free-standing installation or rack-mount (rack-mount kit included).

Details

  • 2 Sources / 4 Channels
    Two analog audio source inputs (balanced or unbalanced) and one digital input.
  • 2 Zones
    Choose between standard stereo zones or a 70V/100V sound system.
  • Full Matrix
    Distribute two audio source inputs to two zones, with the ability to expand to additional zones by daisy-chaining multiple AMP-4-125 units.
  • Powerful Stereo Output
    Delivers 125W power output per channel for stereo zones.
  • Powerful 70V/100V Output
    Provides 250W per channel for 70V/100V zones.
  • Built-In DSP
    Easily configure and optimize DSP and matrix settings through the intuitive web user interface.
  • Ultra-Efficient
    Cool Power® Class D amplifier technology ensures efficient heat dissipation and low power consumption.
  • Audio Source Versatility
    Supports a combination of analog and digital audio sources for flexibility.
  • Control
    Seamlessly integrate with RTI or third-party control systems via IP, or use GPIO control for volume, standby, mute, or trigger functions.
  • Mounting Options
    Supports free-standing installation with included rack ears and adhesive rubber feet. Rack-mount kit sold separately.

Specifications

  • Feature    Details
  • Analog Sources    4 RCA (Unbalanced Stereo)
  • 4 Phoenix Connector (Balanced Stereo)
  • Digital Sources    1 Coax
