Products

Neutrik

speakON 4 pole chassis connector

Product Code: NU-NLT4MXX-BAG

Brand
Neutrik
RRP $36.00


Quantity In Cart:
Unit of Measure
EACH



1 Year
Features
Replaces NU-NLT4MX-BAG
Technical Specifications
Brands Neutrik
  • Details
  • Downloads
  • Where to Buy
  • Ordering

4 pole male cable connector, black metal housing, chuck type strain relief

This connector is fully compliant to the device standard IEC 62368-1, due to its component certification according to IEC 61984.

The speakON STXX Series was especially designed for heavy duty amplifier-loudspeaker applications like professional touring. The extremely rugged and durable STXX Series features an all metal housing.

Features & Benefits

  • IEC 61984 certified, IEC 62368-1 compliant
  • Uses precise “Quick Lock” system
  • Weatherproof built-in gasket meets IP 54 protection class in mated condition
  • Extremely robust metal housing and glass reinforced V-0 material insert designed for harsh and demanding environment
  • Extra large solder contacts for up to 6 mm² (AWG 10) wires

  • Technical Information
Product
Title NLT4MXX-BAG
Gender male
Electrical
Contact resistance < 2 mΩ
Dielectric strength 2.8 kVac
Insulation resistance >0.1 GΩ (after dampheat)
Rated current per contact 30 A rms continuous
Rated voltage 250 V ac
Attention speakON is NOT to be used as an AC mains or power supply connector!
Mechanical
Cable O.D. 9 - 16 mm
Lifetime > 5000 mating cycles
Wiresize 6 mm²
Wiresize 10 AWG
Termination Solder contacts
Locking device Quick Lock
Material
Contact plating Ag
Contacts Copper Alloy
Shell Zinc diecast, black chrome plated
Insert Polyamide (PA 66)
Strain relief Polyacetal (POM)
Environmental
Temperature range -30 °C to +80 °C
Flammability UL 94 V-0
Protection class IP 54 (mated condition)
Solderability Complies with IEC68-2-20
